■ High quality semiconductor laser and stable cooling system
■ The torch with special nozzle suit able for welding at different angle and position on the work piece
■ Operation easy and get high welding speed and high quality
■ The efficiency can be up 2-10times than TIG welding and economizeon manpower
■ General staff can use it and no need special training
■ You can fit wire by seperate wire feeder system
■ Light hand torch and with 5m original Fiber
■ Long life Acessories and save energy, lower use cost
■ Special safety protection function for welding worker
■ Laser model:continue or modulation
■ Laser wave length:1080nm
■ Cooling system:Fan cooling
■ Welding materials:steel/stainless steel/aluminum/cooper
■ Multi functions:welding,cutting,derusting,weld seam cleaning
■ Smaller size and light weight, easy to moving
■ Remote Style LCD control Panel
| Model | Power Supply | Rate Input Capacity (KVA) | Rate Input Current(A) | Laser power | output power stability | Welding depth of fusion | Laser spot range | Welding speed | Dia of wire | Weight | L*W*H(mm) |
| FR-LA-20E | 1*220V 50/60Hz | 2.5 | 11 | 750W | 2% | 0.5-2.5mm | 0-8mm | 0-120mm/s | 0.8,1.0 | 28kg | 560*240*460 |
| FR-LA-25E | 1*220V 50/60Hz | 3.5 | 15 | 1200W | 2% | 0.5-3.5mm | 0-8mm | 0-120mm/s | 0.8,1.0 | 48kg | 600*250*570 |
| FR-LA-30E | 1*220V 50/60Hz | 4.0 | 17 | 1500W | 2% | 0.5-4.0mm | 0-8mm | 0-120mm/s | 0.8,1.0,1.2 | 48kg | 600*250*570 |
| FR-LA-40E | 1*220V 50/60Hz | 4.5 | 20 | 2000W | 2% | 0.5-5.0mm | 0-8mm | 0-120mm/s | 0.8,1.0,1.2,1.6 | 55kg | 650*310*570 |
ACCESSORIES ■ Wire feeder ■ Torch 5m ■ Wire feeding hose ■ Protective glass ■ welding and cutting cleaning nozzles ■ wire feed rollers
 |
 |
 |
 |
 |
 |
OPTIONAL ACCESSORIES
■ Torch and system:SUP21S,SUP23T ■ Twin-wire feeder system
 |
 |
 |
Contact JL Industrial Supply Company Limited for High-quality Welding and Cutting Machine.
